5.4" x 15" XStat™ CLS™ Transducer
1" x 1.4" Folded Motion Tweeter
Two 5.25-inch Aluminum-Cone Woofer
Precision Built Vojtko™ Filter

Frequency Response 73–20,000 Hz ±3dB
Horizontal Dispersion 30°
High Frequency Transducer One 1" x 1.4" (2.6cm x 3.6cm) Folded Motion Transducer with 5.25" x 1.75" (13.3cm x 4.4cm) diaphragm.
Mid Frequency Transducer Patented CLS™ XStat™ electrostatic transducer
» Panel Dimensions 5.4" × 15" (13.7 × 38.1cm)
» Radiating Area 81 in2 (522 cm2)
Low Frequency Transducer Two 5.25" (13.4 cm) cast basket, aluminum cone with extended throw driver assembly, non-resonant asymmetrical chamber format; shielded
Sensitivity 89 dB/2.83 volts/meter
Impedance 6 Ohms. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Recommended Amplifier Power 20‒300 watts per channel
Crossover Frequency 460, 4000 Hz
Components Air core coils
Inputs Custom binding posts
Weight 22.5 lbs. (10.2 kg)
Dimensions (with non-skid feet) 7.6" × 29.75" × 9"
(19.3cm × 75.6cm × 22.9cm)
Dimensions (with stand) 10" × 29.75" × 9"
(25.4cm × 75.6cm × 22.9cm)
