CLS™ XStat electrostatic transducer
Ultra rigid AirFrame™
Dual 200 watt Controlled Dispersion
PoweredForce 10-inch aluminum
cone woofers
Precision built advanced topology
Vojtko™ crossover
25 & 50Hz level control
Highly adjustable ETC™ spikes

Frequency Response 24–23,000 Hz ±3dB
Horizontal Dispersion 30°
Vertical Dispersion 44" (112cm) line source
High Frequency Transducer XStat™ CLS™ electrostatic transducer
» Panel Dimensions 44" × 11.3" (111.8 × 28.7cm)
» Radiating Area 497 in2 (3,209 cm2)
Low Frequency Transducer Two 10" (25.4cm) cast basket, high excursion, aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format
Amplifier Woofer: 2 × 200 watts/channel (4 ohms)
Sensitivity 91 dB/2.83 volts/meter
Impedance 4 Ohms, 0.8 at 20kHz. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Recommended Amplifier Power 20‒600 watts per channel
Crossover Frequency 270Hz
Components Custom-wound audio transformer, air core coils, polypropylene capacitors
Audio Controls ±10dB at 25Hz
±10dB at 50Hz
Lighting Control knob to adjust illuminated blue hood logo, back control panel lighting & ground effects lighting
Inputs Custom 5-way binding posts
Power Draw Standby: <1W/channel
Max: 350W/channel
Weight 75 lbs. (34 kg)
Dimensions 60.9" × 12.7" × 21.3"
(154.8cm × 32.2cm × 54cm)
