44" x 9.2" XStat™ CLS™ Transducer
200W 8-inch PoweredForce™ Woofer
24-bit Vojtko™ DSP Engine
8-inch Passive Radiator

Frequency Response 34–23,000 Hz ±3dB
Horizontal Dispersion 30°
Vertical Dispersion 44" (112cm) line source
High Frequency Transducer XStat™ CLS™ electrostatic transducer
» Panel Dimensions 44" × 9.2" (111.8 × 23.4cm)
» Radiating Area 405 in2 (2,616 cm2)
Low Frequency Transducer 8" (20.3cm) cast basket, high excursion, aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format. 8" (20.3cm) cast basket, high excursion, polypropylene cone passive radiator.
Amplifier Woofer: 200 watts/channel (4 ohms)
Sensitivity 92 dB/2.83 volts/meter
Impedance 4 Ohms, 0.8 at 20kHz. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Recommended Amplifier Power 20‒500 watts per channel
Crossover Frequency 375Hz
Components Custom-wound E-I core transformer, air core coils, polypropylene capacitors. 24-bit DSP based pre-amplifier (used with woofer amplifier).
Audio Controls ±10dB under 100 Hz
Inputs Custom 5-way binding posts
Power Draw Idle: < 1W/channel
Max: 200W/channel
Weight 42 lbs. (19 kg)
Dimensions 59.33" × 10.73" × 18.23"
(150.7cm × 27.3cm × 46.3cm)
