Oyaide Power Receptacle R-0 20Amp Beryllium Copper - Unplated

The Oyaide R-0 receptacle / outlet has a High Quality Beryllium Copper base material, unplated. 20 AMP rating.

The naked receptacle! No plating, just high quality bare copper.

With the introduction of the R1, the category of wall outlet / receptacles may now be said to have reached the stage of true maturity.

Contacts are made of beryllium copper which had previously proven its superiority in the ultra high performance Oyaide M1/F1.

 Base Material: Highly (twice) polished beryllium copper

Mounting Bracket: 24 Karat plated brass fittings for strength and durability of the Body and Insulator. The 1.5mm thick gold mounting frame has high strength and protects against feedback of unnecessary vibrations from the wall. The housing of the R-0 made with the ultimate in design and materials.

All screws are made of stainless steel. Due to its high rigidity, there is no problem such as a screw head rounded off. The maximum cable size is 5.5sq. inches. Thorough testing, the cable has never separated from the plug by a force less than 30kg.

Chassis is Highly rigid Glass filler, Polybutylene terephthalate for resonance control

To complete the R-0, the the material which was punched out as a part is polished by hand, piece by piece after machine barrel-polishing.

The contact of the R0 is made of beryllium copper, same as the R1 and F1/M1 series using a new and high level of performance. The use of heat treated beryllium copper insures mechanical integrity and high conductivity. It is 1.0mm thick and 6.0mm in wide, reducing vibration at the point of contact with no loss of signal transmission.

Specifications: Outlet 2 pole 3 wire grounding 20A 125V

Wire Insert Accepts 4 X 10 Gauge wire allowing for easy flow of high current
