SpecificationsSpecifications

Technical features Diamond Tweeter Anti-resonance plug Flowport Continuum cone bass mid Solid body tweeter Tweeter on top Optimised Matrix

Description 2-way vented-box system

Drive units 1x ø25mm (1 in) diamond dome high-frequency1x ø165mm (6.5 in) Continuum® cone bass midrange

Frequency range 34Hz to 35kHz

Frequency response 42Hz to 28kHz (+/-3dB from reference axis)

Sensitivity 88dB SPL (2.83Vrms at 1m)

Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis)<1 % 70Hz - 20kHz<0.6% 120Hz - 20kHz

Nominal impedance (min) 8Ω (minimum 4.6Ω)

Recommended amplifier power 50W - 120W into 8Ω on unclipped programme

Max. recommended cable impedance 0.1Ω

Height: 424mm Width: 238mm Depth: 345mm

Net weight 12.6kg (28lb)
